Specification Specifications

Six hundred and fifty

Eight hundred

Max working width Maximum working width

630mm

780mm

Max working thickness Maximum working thickness

20mm

20mm

Temperature range temperature range

50-130°C

50-130°C

Speed speed

15m/min

15m/min

Power supply Power Supply

AC220V/50HZ

AC220V/50HZ

Power consumption power

2KW

2.5KW

Machine dimension Machine size

910x604x520mm

1060x604x520mm

N/G Net weight/Gross weight

86.5KG/130.5KG

104KG/159KG

Packing size Package size

990x930x625mm

1150x710x550mm

Structural characteristics:

The machine is heated by hot plating oil pipe, and the heating is uniformBOPPThe product has the advantages of non-toxic, non-toxic, non-toxic, non-toxic, non-toxic, non-toxic, non-toxic, non-toxic, non-toxic, non-toxic, non-toxic, non-toxic, non-toxic, non-toxic, non-toxic, non-toxic, non-toxic, non-toxic, non-toxic, non-toxic, non-toxic, non-toxic, non-.

It can be widely used in photos, packaging boxes, food boxes, books and magazines, drawings, etcThe surface of printed matter is coated.

Optical mechanical lamination, embossing lamination, one-time molding, fast speed, saving time and cost.

It can be replaced with various pattern sticks, easy to disassemble and assemble, flexible and changeable.

It is equipped with tension device.

Structural characteristics:

1. This machine is using internal heating of plating oil tube, uniform heating. It uses bopp film as materials. After the film laminating, the product is highly transparent, viscous, nontoxic and environment-friendly with a strong 3-D appeal and no smell, snowflake spots and bubbles.

2. It can be widely used in Photos, packing box, food box, books and periodicals.

Three It can laminate both plain and pattern. High efficiency, save time and money.

Four Interchangeable pattern roller. Easy disassembly and creations.

Install with tension device.
